Wiring up a gate opener can seem daunting, but with a bit of patience and planning, its a manageable project. The key is understanding the basic electrical connections needed to power the opener and connect the various components like the motor, safety sensors, and control panel.
First, youll need to identify your power source. Most openers require a dedicated 120V AC circuit. This might involve running a new line from your main electrical panel to the opener location. Consult local electrical codes and potentially a qualified electrician if youre unsure about this part. Safety first!
Next, youll connect the power to the openers motor unit. This usually involves connecting wires to clearly labeled terminals inside the motor housing. The wiring diagram included with your opener is your best friend here. Itll show you exactly which wire goes where. Typical colors are black for hot, white for neutral, and green for ground. Make sure all connections are secure and properly insulated.
Safety sensors are crucial for preventing accidents. These are usually photoelectric beams that detect obstructions in the gates path. Wiring these involves running low-voltage wires from the motor unit to each sensor. Again, the wiring diagram will guide you through the specific connections.
Finally, youll connect the control panel, which allows you to operate the gate. This might involve running more low-voltage wires or, in some cases, using wireless technology. Follow the instructions carefully to ensure proper functionality.
Remember, working with electricity can be dangerous. If youre uncomfortable with any part of the wiring process, its always best to consult a qualified electrician. A little professional help can go a long way in ensuring a safe and properly functioning gate opener.
Testing and Adjustments: The Final Touch in Gate Opener Installation
Installing a gate opener involves more than just bolting on the hardware. The real magic, and the key to long-term satisfaction, lies in the meticulous testing and adjustments that follow. This crucial final stage ensures smooth, safe, and reliable operation for years to come.
After the physical installation is complete, the first step is to test the gates movement. Does it open and close smoothly? Are there any points of friction or binding? This is where careful observation comes into play. Watch the gate through a full cycle, listening for unusual noises and looking for any jerky movements or hesitations. Minor adjustments to the operator arm, track alignment, or hinges can often resolve these issues.
Next comes the safety testing. Obstruction sensors are critical safety features and must be thoroughly checked. Testing involves placing objects in the gates path to ensure the sensors detect them and stop the gates movement. Pressure sensitivity should be adjusted so the gate reverses with minimal force, preventing damage to vehicles or, more importantly, injury to people or pets. Similarly, the auto-close feature needs adjustment to ensure it closes the gate securely after a reasonable amount of time, balancing security with practicality.
Force adjustments are equally important. The gate opener should have enough power to operate reliably in various weather conditions, but not so much that it poses a safety hazard. Too much force can damage the gate or opener, while too little can lead to the gate getting stuck. Finding the sweet spot requires careful tweaking and observation.
Finally, its essential to educate the homeowner on the operation and maintenance of the gate opener. Explain the various functions, safety features, and troubleshooting procedures. Provide clear instructions on how to manually operate the gate in case of a power outage. This empowers the homeowner to take ownership of their new gate opener and ensures its longevity.
In conclusion, testing and adjustments are not merely a final step in gate opener installation, but an integral part of the process. They ensure the gate operates safely, smoothly, and reliably, transforming a simple installation into a valuable addition to a property.
Troubleshooting a gate opener installation can feel like navigating a labyrinth, but most issues boil down to a few common culprits. Before you throw your hands up in defeat, take a deep breath and consider these points.
One of the first things to check is the power supply. It sounds obvious, but youd be surprised how often a tripped breaker or a loose wire is the root of the problem. Trace the wiring from the opener back to the power source, ensuring everything is securely connected and that the breaker hasnt flipped. If youre using a solar-powered system, make sure the panels are clean and receiving adequate sunlight. A weak battery can also cause intermittent issues.
Next, inspect the safety sensors. These little guys are crucial for preventing accidents, and if theyre misaligned or obstructed, the gate simply wont move. Check for leaves, debris, or even spiderwebs blocking the sensor beams. A quick wipe and a slight adjustment might be all it takes. If the sensors themselves seem damaged, theyre usually inexpensive and easy to replace.
Mechanical issues can also throw a wrench in the works. Examine the gates tracks and rollers for any signs of damage, blockage, or excessive wear and tear. A bent track or a seized roller can prevent the gate from moving smoothly. Lubricating the moving parts with a suitable lubricant can often resolve these issues. Also, make sure the gate itself isnt binding or catching on anything.
Sometimes, the problem lies within the opener's control board or the remote. Try reprogramming the remote or checking the batteries. If you suspect a control board issue, it's best to consult the manufacturers instructions or contact a professional. These components can be complex, and attempting a DIY repair might do more harm than good.
Finally, if you've exhausted all these options and your gate is still giving you grief, don't hesitate to call in a qualified technician. They have the expertise and specialized tools to diagnose and fix more complex problems. Sometimes, a fresh pair of eyes is all you need to get your gate back on track. Remember, a little troubleshooting can go a long way, but knowing when to call for help is just as important.
Keeping your automatic gate opener running smoothly and safely doesnt have to be a headache. A little regular maintenance and attention to safety can prevent most problems and ensure your gate continues to operate reliably for years to come.
First, lets talk about keeping things moving. Just like your car, your gate opener needs occasional lubrication. Check your owners manual for the recommended lubricant and frequency, but generally, lubricating the chain, screw, or track every few months will keep things running smoothly and prevent premature wear and tear. While youre at it, inspect the moving parts for any signs of damage or excessive wear. Look for loose bolts, frayed wires, or anything that looks out of place. Catching these small issues early can prevent bigger, more expensive problems down the line.
Safety is paramount when dealing with automatic gates. Regularly test the safety features, such as the photo eye sensors and the reversing mechanism. Make sure the photo eyes are aligned correctly and free of obstructions. You can test them by passing an object through the beam – the gate should stop and reverse. Similarly, test the reversing mechanism by placing a solid object in the gates path. It should reverse upon contact. These safety features are crucial for preventing accidents and injuries.
Keep the area around the gate opener clean and free of debris. Remove any leaves, branches, or other objects that could interfere with its operation. Also, make sure the gate itself is properly balanced and swings freely. A misaligned or binding gate can put extra strain on the opener, leading to premature failure.
Finally, remember that electricity and moving parts can be a dangerous combination. If youre not comfortable performing any of these maintenance tasks yourself, or if you encounter a problem you cant solve, dont hesitate to call a qualified gate technician. Its always better to be safe than sorry. By following these simple maintenance and safety tips, you can keep your automatic gate opener running smoothly and safely for years to come, providing you with security and peace of mind.
An electric gate is a type of gate that can be opened and closed using an electrically powered mechanism.
Driveway gate openers can be the rollback (sliding) type that retracts a gate along the fence or wall on wheels or bearing, or the swing type that draws the gate open or closed on hinges. They are usually operated by a remote controller or a sensor
Articulated gate openers can be used for gates with wide posts allowing opening in small spaces.[1] An easy system for DIY installers as they are simple to install but not as aesthetically pleasing as other motor designs. Also known as Crank arm operators, they are the main type of automation system sold in France, where low aluminium gates are often used.
Under-gate Jack operators usually control the gate by directly moving the pivot point of each gate leaf. This makes the unit ideal cosmetically and also allows for up to 180 degrees of leaf swing as required. However controlling the pivot point of the gate, is like opening a door by twisting the hinge, and as so is very difficult due to the loads needed at that point. This is highlighted with snap, as the gate has to change direct, as soon as it can. For this reason they are recommend as only suitable for ‘Domestic’ systems in a low risk of abuse environment. Another major consideration with the use of under-gate units is that of water immersion/ingress and warranty voidance. If the water table is high or the drainage of the unit's foundation box inadequate throughout the systems life, then water ingress and unit failure is increased.
Ram or link arm units are usually simpler to install and maintain, they are visible to otherwise ignorant abuse and as they fix down along each gate leaf, they also have an obvious and sometimes major, mechanical advantage over Jacks. Therefore, Rams are far more suitable on Multi-user & commercial systems. Also the manual release is always above ground, making it often more user friendly in operation.
If space is an issue or the driveway behind the gates is on a steep incline, a better option would be a sliding gate. Sliding gates are also very popular in a commercial environment. Sliding gates are also used for cantilever gate systems.
One of the first electric gates was invented by a Canadian Fred W. Watson in 1881. It was designed to be used for railway systems.[2] In 1884, a number of American newspapers reported that the French railway companies were about to adopt an electric gate opener. “A catch connected with an electro-magnet keeps a gate closed,” reported The National Tribune on October 9, 1884.[3] One of the early demonstrations of such gates in the United States was arranged by the short-lived Toulmin Electric Railway Gate Company in 1887, in Baltimore.[4] At the end of the 19th century, electric gates were also used at horse racing tracks.[5]
The first commercial electric gate systems were hydraulic and designed for reliability and ease of use. The cost of the hydraulic systems however meant that other companies started producing more affordable electromechanical alternatives. Hydraulic motors are the preferred choice on large and heavy gates as they can generate high levels of torque, electromechanical systems designed for lower usage domestic installations because they can be produced more cost effectively.[6]
The backbone of any electric gate, whether automatic or not, is the electric gate motor, two distinct motor types exist hydraulic, or electromechanical. This is the electric device which actually enables the electric gate to open and close without having to manually push the gate.
The safety of an automated gate is an important consideration, in the European Union, automated gate safety is specified by a series of European Normalisations. An automated gate that has not been fitted with safety in mind can potentially become a major hazard particularly to untrained users. Various safety devices are available to make sure that your gates meet the highest of European or American safety standards.
Since electric gates operate slowly, they are susceptible to "tailgating" threats, in which a person or vehicle sneaks in behind an authorized user.[7] If security is a concern, a video surveillance camera should be installed.[7]
Electric gates alone, however solid and imposing they may be, cannot guarantee a completely secure environment electric locks, are often needed to boost the locking effectiveness of the gate motors. Electric gates are recommended to be used in combination with other security features to install a full security system. A few of these features are closed circuits with security cameras, additional gates in conjunction with the main gate, electronic keycards and keypads, security guards.[8]
Aside from the additional security features that should go with parking barrier gates, electric security gates often offer safety features like sensors that determine when there is an obstruction to prevent the electronic gate from swinging into a vehicle or closing on somebody's hands. To prevent the electronic gates from being damaged by irresponsible drivers driving fast speed bumps are also commonly placed before gate entrances to slow down vehicles.
In the United States all the electric gate installations must meet Underwriters Laboratories 325 (UL 325) standard while in Europe installations must meet with the Machinery directive 2006/42/EC with EN13241-1 being the regulations concerning gates.[9][10][11][12]
The installer of the gate is responsible for the conformity to regulation, not the manufacturer. The two main EN regulations that then apply are EN 12453 which describes the safety levels that should be observed when installing a gate and EN12445 which describes the testing method that must be undertaken.[13]
The major points are the maximum amount of force at certain test points. Example - a maximum of 400N of force can be applied in the last 50, 300 and 500 mm of travel of a gate, after the initial impact the force must drop to 150N within 0.75 of a second and reduce to 25N within 5 seconds. During the mid travel of a gate the allowable force is 1400N. A full risk assessment of the gates must take place with all crush, cutting points shown to the client with appropriate protection devices offered, a recommended maintenance program should also be provided. Finally the installer must confirm that all electrical equipment fitted has the European CE mark all the time.
To conform to these regulations the gate system must be checked with a calibrated force tester and the full results kept in a technical file for 7 years. If the gate is not tested it does not comply.
Most gate kits can be fitted with safety equipment so that these limits are achieved and so cover that part of EN13241-1.
In September 2010, following two incidents in Bridgend and Manchester, when children were killed by sliding gates, the UK Health and Safety Executive issued 2 safety notices aimed at gate manufacturers and installers, demanding them to comply with the Annex A of BS EN 12453:2001 standard.[14][15]
In recent years, aluminium has emerged as the material of choice for driveway gates in the UK, and for good reason. One of the key reasons for this shift is the ease with which aluminium gates can meet force limitation guidance. Force limitation refers to the maximum amount of force that a gate can exert on an object or person, ensuring safety and minimizing the risk of accidents or injuries. With lightweight aluminium gates, meeting these force limitation guidelines becomes much more achievable, as they require less force to open and close compared to heavier materials such as wrought iron or steel.
Another advantage of aluminium gates is their compatibility with brushless motor operators. Brushless motors offer numerous benefits over traditional brushed motors, including higher efficiency, longer lifespan, and reduced maintenance requirements. Aluminium gates, being lightweight, work well with brushless motor operators, as the motors do not have to work as hard to maneuver the gates. This not only enhances the overall performance and reliability of the gate system but also contributes to energy efficiency, leading to cost savings in the long run.
Furthermore, aluminium gates provide additional advantages such as resistance to rust and corrosion, making them a durable and low-maintenance option. They are also highly customizable, allowing homeowners to choose from a wide range of designs, colors, and finishes to match their aesthetic preferences. Additionally, aluminium is a sustainable material as it can be recycled, aligning with the growing trend of eco-consciousness in the construction and home improvement industries.
[16]
Overall, the combination of meeting force limitation guidance more easily, compatibility with brushless motor operators, durability, low maintenance, and customizability has made aluminium the material of choice for driveway gates in the UK. With its numerous benefits, it offers homeowners a reliable, safe, and aesthetically pleasing option for enhancing the security and curb appeal of their properties.
A fence is a structure that encloses an area, typically outdoors, and is usually constructed from posts that are connected by boards, wire, rails or netting.[1] A fence differs from a wall in not having a solid foundation along its whole length.[2]
Alternatives to fencing include a ditch (sometimes filled with water, forming a moat).
A balustrade or railing is a fence to prevent people from falling over an edge, most commonly found on a stairway, landing, or balcony. Railing systems and balustrades are also used along roofs, bridges, cliffs, pits, and bodies of water.
Another aim of using fence is to limit the intrusion attempt into a property by malicious intruders. In support of these barriers there are sophisticated technologies that can be applied on fence itself and strengthen the defence of territory reducing the risk.
The elements that reinforce the perimeter protection are:
In most developed areas the use of fencing is regulated, variously in commercial, residential, and agricultural areas. Height, material, setback, and aesthetic issues are among the considerations subject to regulation.
The following types of areas or facilities often are required by law to be fenced in, for safety and security reasons:
Servitudes[6] are legal arrangements of land use arising out of private agreements. Under the feudal system, most land in England was cultivated in common fields, where peasants were allocated strips of arable land that were used to support the needs of the local village or manor. By the sixteenth century the growth of population and prosperity provided incentives for landowners to use their land in more profitable ways, dispossessing the peasantry. Common fields were aggregated and enclosed by large and enterprising farmers—either through negotiation among one another or by lease from the landlord—to maximize the productivity of the available land and contain livestock. Fences redefined the means by which land is used, resulting in the modern law of servitudes.[7]
In the United States, the earliest settlers claimed land by simply fencing it in. Later, as the American government formed, unsettled land became technically owned by the government and programs to register land ownership developed, usually making raw land available for low prices or for free, if the owner improved the property, including the construction of fences. However, the remaining vast tracts of unsettled land were often used as a commons, or, in the American West, "open range" as degradation of habitat developed due to overgrazing and a tragedy of the commons situation arose, common areas began to either be allocated to individual landowners via mechanisms such as the Homestead Act and Desert Land Act and fenced in, or, if kept in public hands, leased to individual users for limited purposes, with fences built to separate tracts of public and private land.
Ownership of a fence on a boundary varies. The last relevant original title deed(s)[8] and a completed seller's property information form may document which side has to put up and has installed any fence respectively; the first using "T" marks/symbols (the side with the "T" denotes the owner); the latter by a ticked box to the best of the last owner's belief with no duty, as the conventionally agreed conveyancing process stresses, to make any detailed, protracted enquiry.[9] Commonly the mesh or panelling is in mid-position. Otherwise it tends to be on non-owner's side so the fence owner might access the posts when repairs are needed but this is not a legal requirement.[10] Where estate planners wish to entrench privacy a close-boarded fence or equivalent well-maintained hedge of a minimum height may be stipulated by deed. Beyond a standard height planning permission is necessary.
Where a rural fence or hedge has (or in some cases had) an adjacent ditch, the ditch is normally in the same ownership as the hedge or fence, with the ownership boundary being the edge of the ditch furthest from the fence or hedge.[11] The principle of this rule is that an owner digging a boundary ditch will normally dig it up to the very edge of their land, and must then pile the spoil on their own side of the ditch to avoid trespassing on their neighbour. They may then erect a fence or hedge on the spoil, leaving the ditch on its far side. Exceptions exist in law, for example where a plot of land derives from subdivision of a larger one along the centre line of a previously existing ditch or other feature, particularly where reinforced by historic parcel numbers with acreages beneath which were used to tally up a total for administrative units not to confirm the actual size of holdings, a rare instance where Ordnance Survey maps often provide more than circumstantial evidence namely as to which feature is to be considered the boundary.
On private land in the United Kingdom, it is the landowner's responsibility to fence their livestock in. Conversely, for common land, it is the surrounding landowners' duty to fence the common's livestock out such as in large parts of the New Forest. Large commons with livestock roaming have been greatly reduced by 18th and 19th century Acts for enclosure of commons covering most local units, with most remaining such land in the UK's National Parks.
A 19th-century law requires railways to be fenced to keep people and livestock out.[12] It is also illegal to trespass on railways, incurring a fine of up to £1000.
Distinctly different land ownership and fencing patterns arose in the eastern and western United States. Original fence laws on the east coast were based on the British common law system, and rapidly increasing population quickly resulted in laws requiring livestock to be fenced in. In the west, land ownership patterns and policies reflected a strong influence of Spanish law and tradition, plus the vast land area involved made extensive fencing impractical until mandated by a growing population and conflicts between landowners. The "open range" tradition of requiring landowners to fence out unwanted livestock was dominant in most of the rural west until very late in the 20th century, and even today, a few isolated regions of the west still have open range statutes on the books. More recently, fences are generally constructed on the surveyed property line as precisely as possible. Today, across the nation, each state is free to develop its own laws regarding fences. In many cases for both rural and urban property owners, the laws were designed to require adjacent landowners to share the responsibility for maintaining a common boundary fenceline. Today, however, only 22 states have retained that provision.
Some U.S. states, including Texas, Illinois, Missouri, and North Carolina, have enacted laws establishing that purple paint markings on fences (or trees) are the legal equivalent of "No Trespassing" signs. The laws are meant to spare landowners, particularly in rural areas, from having to continually replace printed signs that often end up being stolen or obliterated by the elements.[13]
The value of fences and the metaphorical significance of a fence, both positive and negative, has been extensively utilized throughout western culture. A few examples include:
Notes
Bibliography
A gate or gateway is a point of entry to or from a space enclosed by walls. The word is derived from Proto-Germanic *gatan, meaning an opening or passageway.[1] Synonyms include yett (which comes from the same root word) and portal. The concept originally referred to the gap or hole in the wall or fence, rather than a barrier which closed it. Gates may prevent or control the entry or exit of individuals, or they may be merely decorative. The moving part or parts of a gateway may be considered "doors", as they are fixed at one side whilst opening and closing like one.[2]
A gate may have a latch that can be raised and lowered to both open a gate or prevent it from swinging.[3] Gate operation can be either automated or manual. Locks are also used on gates to increase security.
Larger gates can be used for a whole building, such as a castle or fortified town. Doors can also be considered gates when they are used to block entry as prevalent within a gatehouse.
